MEANWELL UHP Series PFC Switching Power Supply - 5V / 12V / 24V / 36V / 48V DC Output Voltage | 200W / 350W / 500W | AC90-264V | UL / CE Certified
MEANWELL UHP Series PFC Switching Power Supply - 5V / 12V / 24V / 36V / 48V DC Output Voltage | 200W / 350W / 500W | AC90-264V | UL / CE Certified
MEANWELL UHP Series PFC Switching Power Supply - 5V / 12V / 24V / 36V / 48V DC Output Voltage | 200W / 350W / 500W | AC90-264V | UL / CE Certified
Package Included
| Version | Package Included |
| 5V 200W 1-Pack | 1 × MEANWELL UHP Series Power Supply (5V / 200W), user manual |
| 12V 200W 1-Pack | 1 × MEANWELL UHP Series Power Supply (12V / 200W), user manual |
| 24V 200W 1-Pack | 1 × MEANWELL UHP Series Power Supply (24V / 200W), user manual |
| 36V 200W 1-Pack | 1 × MEANWELL UHP Series Power Supply (36V / 200W), user manual |
| 48V 200W 1-Pack | 1 × MEANWELL UHP Series Power Supply (48V / 200W), user manual |
| 5V 350W 1-Pack | 1 × MEANWELL UHP Series Power Supply (5V / 350W), user manual |
| 12V 350W 1-Pack | 1 × MEANWELL UHP Series Power Supply (12V / 350W), user manual |
| 24V 350W 1-Pack | 1 × MEANWELL UHP Series Power Supply (24V / 350W), user manual |
| 36V 350W 1-Pack | 1 × MEANWELL UHP Series Power Supply (36V / 350W), user manual |
| 48V 350W 1-Pack | 1 × MEANWELL UHP Series Power Supply (48V / 350W), user manual |
| 5V 500W 1-Pack | 1 × MEANWELL UHP Series Power Supply (5V / 500W), user manual |
| 12V 500W 1-Pack | 1 × MEANWELL UHP Series Power Supply (12V / 500W), user manual |
| 24V 500W 1-Pack | 1 × MEANWELL UHP Series Power Supply (24V / 500W), user manual |
| 36V 500W 1-Pack | 1 × MEANWELL UHP Series Power Supply (36V / 500W), user manual |
| 48V 500W 1-Pack | 1 × MEANWELL UHP Series Power Supply (48V / 500W), user manual |
About this item
- Slim and low-profile housing: 26mm thickness for 200W, 31mm for 350W/500W
- Fanless design: 200W supports convection cooling; silent operation for compact installations
- Wide input AC 90–264V with built-in active PFC function
- Withstands 300VAC surge input for 5 seconds for improved input resilience
- 150% peak load capability (100ms) to handle short-term load spikes
- Operating temperature range: -20°C to 70°C for demanding environments
- Protections: short circuit, overload, over voltage, over temperature
- DC OK active signal and redundant function available (optional, model-dependent)
- Operating altitude up to 5000 meters (note requirement may apply)
- LED power-on indicator and 3-year warranty
Order & Logistics
- Lead Time: Ships within 1–3 business days.
- Packing: Cardboard box.
- Shipping Note: This series enjoys our Free Shipping Policy for orders over $399. Most items in this series are stocked in our local warehouses in the US, UK, and Germany for 3–7 day delivery. If an item is out of stock locally, it will ship from our headquarters warehouse: 9–18 days standard or 5–9 days express.
Key Specifications
- Input Voltage: AC 90–264V, 50/60Hz
- Output Voltage Options: 5V DC / 12V DC / 24V DC / 36V DC / 48V DC
- Output Power Options: 200W / 350W / 500W
- Profile Thickness: 26mm (200W); 31mm (350W/500W)
- Cooling: Fanless; 200W convection cooling
- Active PFC: Built-in active PFC function
- Surge Withstand: 300VAC input surge for 5 seconds
- Peak Load: 150% peak load capability (100ms)
- Operating Temperature: -20°C to 70°C
- Altitude: Up to 5000 m (note requirement may apply)
- Protection: Short circuit, overload, over voltage, over temperature
- Indicator: LED power-on indicator
- Certification: UL / CE
- Warranty: 3 years
Technical Specifications
| Model | UHP-200-5 | UHP-200-12 | UHP-200-24 | UHP-200-36 | UHP-200-48 | UHP-350-5 | UHP-350-12 | UHP-350-24 | UHP-350-36 | UHP-350-48 | UHP-500-5 | UHP-500-12 | UHP-500-24 | UHP-500-36 | UHP-500-48 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated output voltage | 5V DC | 12V DC | 24V DC | 36V DC | 48V DC | 5V DC | 12V DC | 24V DC | 36V DC | 48V DC | 5V DC | 12V DC | 24V DC | 36V DC | 48V DC |
| Rated output current | 40A | 16.7A | 8.4A | 5.6A | 4.2A | 60A | 29.2A | 14.6A | 9.75A | 7.3A | 80A | 41.7A | 20.9A | 13.9A | 10.45A |
| Output current range | 0–40A | 0–16.7A | 0–8.4A | 0–5.6A | 0–4.2A | 0–60A | 0–29.2A | 0–14.6A | 0–9.75A | 0–7.3A | 0–80A | 0–41.7A | 0–20.9A | 0–13.9A | 0–10.45A |
| Rated output power | 200W | 200.4W | 201.6W | 201.6W | 201.6W | 300W | 350W | 350.4W | 351W | 350.4W | 400W | 500.4W | 501.6W | 500.4W | 501.6W |
| Ripple & noise (max) | 200mVp-p | 240mVp-p | 240mVp-p | 240mVp-p | 300mVp-p | 200mVp-p | 200mVp-p | 240mVp-p | 240mVp-p | 240mVp-p | 200mVp-p | 200mVp-p | 240mVp-p | 360mVp-p | 360mVp-p |
| Efficiency (typ.) | 91% | 93% | 94% | 94% | 94% | 90% | 91% | 92% | 94% | 94% | 94% | 94% | 94.5% | 95% | 95% |
| Input voltage range | AC 90–264V / DC 127–370V | ||||||||||||||
| Frequency range | 47–63Hz | ||||||||||||||
| Product dimensions (L × W × H) | 194 × 55 × 26 mm | 220 × 62 × 31 mm | 232 × 81 × 31 mm | ||||||||||||
| Operating temperature | -30°C to +70°C | ||||||||||||||
| Protection | Short circuit / Overload (110%–140%) / Over voltage / Over temperature | ||||||||||||||
| Cooling | Built-in cooling fan (forced air cooling) | ||||||||||||||
| Safety & compliance | UL / TUV / CE / BIS / EAC (model dependent) | ||||||||||||||
Usage Notes / Installation Tips
- Confirm the required DC output voltage (5V/12V/24V/36V/48V) before ordering
- Select wattage based on total load and keep headroom for stable operation
- Disconnect AC power before wiring or adjusting terminals
- Provide adequate ventilation and avoid sealing the unit in an unventilated enclosure
- Follow local electrical codes when integrating into systems or cabinets
Applications
- Industrial control systems and automation equipment
- LED lighting systems requiring stable DC output
- Test benches, labs, and electronic prototyping
- 3D printers, CNC peripherals, and DIY electronics
- Communication equipment and embedded systems
