Neon Light Housing – S22D | ⏀22mm Silicone LED Channel System | IP67 Waterproof | 6mm PCB Width | 164FT/50M

Neon Light Housing – S22D | ⏀22mm Silicone LED Channel System | IP67 Waterproof | 6mm PCB Width | 164FT/50M

Package Included

Version	Package Included
Compatible LED: 6mm Strip / Pack Size: 164FT (50M × 1)	50m silicone LED channel tube (cuttable) 100 × end caps 150 × mounting clips 150 × screws (LED strip not included)
Compatible LED: 6mm Strip / Pack Size: 16.4FT (5M × 10)	10 × 5m silicone LED channel tubes (cuttable) 100 × end caps 150 × mounting clips 150 × screws (LED strip not included)

About this item

• Flexible and easy to cut, made of 100% silicone; bend into different shapes freely and cut to the required length
• All-black housing with anti-dazzle extrusion technology for uniform luminous surface and improved lighting performance
• Compatible with ≤ 6 mm LED light strips (such as 2835/3528/5050 types); waterproof LED strips not applicable
• IP67 water and dust resistant; seal end caps with adhesive when used in moist environments; rainproof and withstands short-term immersion (not for long-term submersion)
• Easy to install; fasten LED strip and pull through channel; includes end caps and mounting clips; supports surface mount or recessed wall installation
• Wide applications including under-cabinet, backsplash, accent, and decorative lighting; suitable for kitchens, cabinets, patios, living rooms, and temporary outdoor party use

Order & Logistics

Lead Time

• Ships directly from headquarters. Handling time 3–5 business days

Shipping Note

• This series enjoys our Free Shipping Policy for orders over $399.
• HQ Fulfillment (when local stock is unavailable): Standard 9–18 days  |  Express 5–9 days.
• Packing: Cardboard box

Key Specifications

• Compatible LED Strip Width: 6 mm
• Pack Size: 164FT/50M × 1; 16.4FT/5M × 10
• Housing Size: Ø 22 mm
• Beam Angle: 120°
• Housing Color: All black, integrated design
• Material: 100% silicone
• Waterproof Rating: IP67 (requires sealed end caps with gel)
• Light Source Compatibility: SMD 2835, 3528, 5050, etc.
• Working Temperature: -20°C to 50°C
• Accessories per 5 m: 5 × End Caps (with hole), 5 × End Caps (without hole), 15 × Mounting Clips

Usage Notes / Installation Tips

• LED strip not included; purchase separately
• Ensure LED strip width ≤ 6 mm for proper fit
• Use high-density LED strips (e.g., SMD2835-600) for spotless lighting effect
• Housing lengths can be customized; contact for special needs
• Cut housing carefully and straight with proper scissors; uneven sections affect sealing with end caps
• Apply lubricating oil or wax to LED strip back for smoother installation; manual insertion recommended only up to 10 m length

Applications

• Under-cabinet and backsplash lighting
• Accent and decorative lighting
• Kitchen, cabinet, and living room setups
• Outdoor projects with IP67 waterproof protection
• Temporary installations for parties and events
