49.5 Inch (1210×340mm Viewable) Ultra-Wide Stretched LCD Shelf Display | Android Bar Screen | Cloud Platform & USB Playback

Package Included

Version	Package Included
TXP-49.5"	LCD Bar Display ×1, Power Plug Cable ×1, Remote Controller ×1 (battery not included), Mounting Screws & Expansion Tubes ×1, Honeycomb Cardboard Box ×1, User Manual ×1

About this item

• 49.5-inch ultra-wide LCD bar screen with Android OS, ideal for retail shelves, signage, and creative displays
• 3840×1080 resolution with LED backlight for vivid colors, wide 178° viewing angle, and 1200:1 contrast ratio
• RK3568 quad-core processor with Android 11, supporting 4K/H.265 decoding and smooth playback
• Durable metal casing with tempered glass, resistant to interference and built for long service life
• Multiple control options: Cloud CMS, LEDArt App, USB plug & play, LAN/Wi-Fi; optional capacitive touch for interactive use

Order & Logistics

• Lead Time: If stock is available, ships within 5 business days. For models requiring production, the typical lead time is 10–15 business days.
• Packing: Hard carton with protective inner foam.
• Shipping:

• Free Freight (DDP): 10–20 days (Air + Ground) — economy air shipping, freight already included in product pricing.
• Priority Freight (DDP): 7–15 days (Air + Ground) — faster delivery option at checkout.
• DDP Terms: Customs clearance, duties, and taxes are included. If DDP service is not available in your destination country, we will coordinate alternative terms (e.g., EXW / FOB) with you to ensure smooth delivery.

Specifications

Category	Details
Screen Size	TXP-49.5"
Screen Supplier	LG
Resolution	3840×1080
Display Size	1210 × 340 mm
Brightness	500 cd/m²
Contrast Ratio	1200:1
Viewing Angle	178° (89/89/89/89 Min. CR≥10)
Response Time	8 ms (typical)
Display Color	1.07 G
Pixel Pitch	0.27963 × 0.27963 mm
Refresh Rate	60 Hz
Motherboard	RK3568, Quad-Core ARM Cortex-A55, 2.0 GHz, Mali-G52 GPU
Memory	2 GB RAM + 16 GB Storage
System	Android 11
Interfaces	USB3.0, OTG, TF-card, Audio, RJ45, HDMI in
Audio	Optional speakers
Remote	Infrared remote controller (optional)
Net Weight	~12 kg
Device Size	1252 × 384 × 56 mm
Casing Material	Metal sheet
Power Input Voltage	DC 12V
Device Power	≤55 W
Standby Power	<1 W
Operating Temp.	0℃–50℃
Operating Humidity	10%–90% RH (non-condensing)
Storage Temp.	-20℃–60℃
Storage Humidity	5%–95% RH (non-condensing)
OSD Language	English / Chinese
Touch Screen	Capacitive Touch Screen Optional

Usage Notes / Operation Tips — Content Upload Methods

Send Program via Cloud Platform	Send Program via LEDArt	Play Program via U-disk / SD Card
Operation Steps: 1. Login cloud platform 2. Create and edit programs 3. Send programs to the device	Operation Steps: 1. Run mobile app LEDArt 2. Create and edit programs 3. Send program to the device	Operation Steps: 1. Save programs into U-disk or SD Card 2. Insert U-disk or SD Card 3. Playback program automatically
Notes: Must be set to networking mode and associated with the account	Notes: Must be set to stand-alone mode; phone and device must be in the same network	Notes: Must be set to stand-alone mode; U-disk/SD Card format must be FAT32

Applications

• Retail shelf-edge displays
• Shopping mall signage
• Exhibition & trade show displays
• Airport / metro / bus station information boards
• Creative installations & advertising walls

Downloads

• 📄 Datasheet for 49.5'' Stretched LCD Display Screen
• 📄 HUIDU Cloud Platform Content Management Software Manual
• 📲 Send via "LEDArt" APP
• 📲 Send program to LCD display screen by HUIDU Mobile APP LEDArt
• 💻 Play via U-Disk/SD Card
• 🎛️ Remote Controller (Auxiliary Control)
• 🔄 How to rotate the screen
• 🌐 How to set fixed IP address
• ⬆️ How to upgrade MagicPlayer
• 🖥️ Splice Multiple LCD Digital Signages On XiaoHui Cloud
